  • Product Details

    Dual pole 500A Master Disconnect Switch cuts all battery power from vehicle electrical systems with applications needing switching of two circuits, or both positive and negative.

    Max operating voltage: 48V DC
    Cranking rating (30sec): 2250A per circuit, with 2 x 4/0 input and 2 x 4/0 output cables 1750A per circuit, with 1 x 4/0 input and 1 x 4/0 output cables
    Integer ut purus ac augue commodo commodo. Nunc nec mi eu justo tempor consectetuer.
    Inrush rating (1 sec): 3000A per circuit with 2 x 4/0 + 1 x 2 AWG
    Terminal stud size: M12 x 25mm.
    Temperature range: -50° to 85°C, DC-Rated to 105°C
